| ब्रांड नाम: | Skyline |
| मॉडल संख्या: | SL-FL609 |
| मूक: | 1 |
| कीमत: | विनिमय योग्य |
| भुगतान की शर्तें: | टी/टी, एल/सी, डी/ए, डी/पी, वेस्टर्न यूनियन, मनीग्राम, नकद में |
| आपूर्ति की योग्यता: | 30 इकाई / महीना |
| Parameter | Specification |
|---|---|
| Weight of pendulum | 1500g ± 30g |
| Distance from the center of gravity of pendulum to the end | 410mm ± 5mm |
| The static pressure of the rubber sheet on the ground | 22.2N ± 0.5N |
| Sliding length of pendulum on the road surface | 126mm ± 1mm |
| Distance from the lower edge of the rubber sheet to the swing center of the pendulum | 510mm ± 2mm |
| Dimension of rubber sheet | 6.35mm x 25.4mm x 76.2mm |
| Shore hardness of rubber sheet | 55 ± 5 HD |
| Pointer | Weight ≤85g, length 300mm ± 1mm |
| The Angle between the rubber sheet and the horizontal | 26 ± 3° |
| Machine Dimension | 620*450*590mm (About 14kg) |
