| ब्रांड नाम: | SKYLINE |
| मॉडल संख्या: | एसएल-आरवीटी |
| मूक: | 1 |
| भुगतान की शर्तें: | टी/टी |
| आपूर्ति की योग्यता: | 1 पीस/माह |
| Test standard | ASTM D4728 or ISO 13355 , ASTM D 4169 |
|---|---|
| Maximum sinusoidal excitation force | 2200 kgf peak |
| Maximum random excitation force | 2200 kgf r.ms |
| Maximum impact excitation force | 4400 kgf peak |
| Frequency range | 1–2600 Hz |
| Maximum displacement | 100 mm p-p |
| Maximum velocity | 2 m/s |
| Maximum acceleration | 100 G (980 m/s²) |
| Load Details |
5 G (50 m/s²) 5.2. Maximum Load (Sine Wave) F = M.A 10G (100 m/s²) 20G (200 m/s²) 30G (300 m/s²) |
| Frequency | 2000 Hz |
| First-order resonance frequency | 2000 Hz |
| Payload | 800 kg |
| Vibration isolation frequency | 2.5 Hz |
| Voice Coil Diameter | 340 mm |
| Voice Coil Mass | 25 kg |
| Table Mounting Screws | 17 * M10 |
| Magnetic Leakage | < 10 Gauss |
| Allowable Eccentric Torque | 1000 N·m |
| Weight | Approx. 2500 kg (excluding horizontal slide) |
